Facilities

Langstone Engineering are situated in a well-equipped facility in the heart of Portsmouth, with great access links for the UK and Europe. Check out our contact us page for a location map.

We offer state of the art manufacturing capabilities using:

  • 5-axis milling capacity up 3000mm x 800mm
  • CNC turning capacity up to 680mm x 750mm
  • 5-axis CNC milling capacity up to 2600mm x 750mm
    (See our full plant list below)
  • Fully equipped hands-on Toolroom
  • Cutting edge temperature controlled inspection department

Workshop machinery: Manual lathes, Mills, Spark eroders, Drilling machines, Band saws, Surface grinders, Shadow graph, Surface table and inspection equipment.

Software

Up to date software options including:

  • CAD/CAM suite
  • VISI Mould and VISI Machining Strategist
  • NCG and Openmind hyperMill software

Accepted File Formats

CATIA
DWG
DXF
IGES
STEP
STL

Plant List

HEDELIUS C125-2500

HEDELIUS C125-2500

2500mm x 1250mm x 770mm Hedelius C 125/2500 ~ 3-axis CNC Mill iTNC 530 control

HEDELIUS T7-1600

HEDELIUS T7-1600

1600mm x 750mm x 695/800mm ~ 5-axis CNC Mill iTNC 530 control

HEDELIUS T7 1R 2600 – 3 Machines

HEDELIUS T7 1R 2600 – 3 Machines

2600mm x 750mm x 695/800mm ~ 5-axis CNC Mill iTNC 530 control

HEDELIUS RS650K – 2 Machines

HEDELIUS RS650K – 2 Machines

1200mm x 650/385mm x 520mm ~ 5-axis Moving Column Vertical CNC Mill iTNC 530 control

HEDELIUS RS805 K23

HEDELIUS RS805 K23

340mm x 800/480mm x 600mm ~ 5-axis Moving Column Vertical CNC Mill iTNC 530 control

HEDELIUS ACURA 65

HEDELIUS ACURA 65

700mm x 650/465mm x 600mm ~ 5-axis high performance CNC Mill iTNC 640 control

HEDELIUS ACURA 65 EL

HEDELIUS ACURA 65 EL

700mm x 650/465mm x 600mm ~ 5-axis high performance CNC Mill iTNC 640 control with Erowa Robot 12 x UPC Pallets (320x320mm)

GOODWAY GCL-2BL

GOODWAY GCL-2BL

230ø x 400mm CNC Turning Centre

DECKEL DMU 100T

DECKEL DMU 100T

1080mm x 710mm x 710mm DECKEL DMU 100T ~ 5-axis Universal Mill TNC530 control

DECKEL DMU 50eVO LINEAR

DECKEL DMU 50eVO LINEAR

500mm x 450mm x 400mm DECKEL DMU 50eVO linear ~ 5-axis CNC Mill iTNC530 control

DECKEL DMU 50

DECKEL DMU 50

500mm x 450mm x 400mm DECKEL DMU 50 ~ 5-axis CNC Mill iTNC 530 3D-control

YCM NSV 102AH – 3 machines

YCM NSV 102AH – 3 machines

1020mm x 600mm x 600mm YCM NSV 102AH ~ 3-axis CNC Mill iTNC 530 smart control

ECOCA MT-412MC

ECOCA MT-412MC

680ø x 750mm CNC Production Lathe

GOODWAY GS-2600Y

GOODWAY GS-2600Y

330ø x 600mm CNC Turning Centre

QCT QUANTUM 4-8305

QCT QUANTUM 4-8305

NC controlled CMM range 3000mm x 800mm x 500mm ~ with Inspect3D measuring software & Inspect2CAD measuring software module, joystick controller & Renishaw PH10 probe system

NICKON 2.5m + MCAz

NICKON 2.5m + MCAz

Inspection Arm with MMD x 100 Laser Scanner with CMM manager / Focus inspection software

DEAMistral CMM

DEAMistral CMM

B&S DEAMistral CMM with PC, Printer & QCT- 2000 measuring software, pneumatic marking & mould polishing equipment

ROMER ABSOLUTE 7525SI 2.5m

ROMER ABSOLUTE 7525SI 2.5m

Inspection Arm with integrated RS4 Laser Scanner with PowerInspect 3D metrology software platform

SODICK AQ75L

SODICK AQ75L

700mm x 500 x 350mm – Linear motor EDM Die sinking Machine-CNC controlled axis movement

Other equipment includes:

Manual lathes, Mills, Spark eroders, Drilling machines, Band saws, Surface grinders, Surface table, Shadow graph and Inspection apparatus.
